PTDC Explosion-proof Digital Temperature Controller

Rated Voltage

AC220V

Operating Ambient Temperature

-60°C ~ 55°C

Rated Current

32A

Measured Process Temperature

-40°C ~ 125°C

Product Temperature Class

T4, T135°C

Ref No.

Details

Ambient Temperature Range

-60°C ~ +55°C

Relative Humidity

≤95% RH

Housing Material

Increased-safety polyester, black

Dimensions

160mm × 160mm × 90mm (L×W×D)

Protection Rating

IP66

Electrical Data

Rated Voltage

AC220V (-10% ~ +20%), 50Hz (47Hz~63Hz)

Rated Current

32A

Sensor Type

PT100, 3-wire

Measurement Range

-60°C ~ +200°C

Cable Entries

Power Supply

1×M25 gland

Heat Tracing Cable

1×M25 gland

Communication/Alarm

1×M16 gland or plug

Sensor

1×M16 gland

Weight

~3.3kg

Measurement Accuracy

±1K @ 5°C

No-load Power Consumption

Pmax=5VA

Full-load Power Consumption

Pmax=7kVA

Alarm Relay Contact Capacity

5A 250Vac

Communication Protocol

Modbus RTU

Communication Hardware

RS485
